Name: E14 52mm UVC Germicidal Tubes UV Ozone Lamp T5G5 White Aluminum Base
Brand: UV, Yoway
SKU: ZW3D17Y-Z52
Price: 3 USD
Availability: InStock
Rating: 4.9 (129 reviews)

Detail Information

Application:	Disinfection Cabinet, Sterilizing Boxes	Lamp:	Single-ended
Life Span:	10000 Hours	Warranty:	12 Months
Material:	99%	DIAMETER:	17
LENGTH:	52mm	OZONE:	OZONE/FREE
Mercury:	Liquid Mercury	ITEM:	ZW3D17Y-Z52
High Light:	E14 52mm UVC Germicidal Tubes , uv ozone lamp T5G5 White Aluminum Base , E14 52mm uv ozone lamp

Product Description

E14 52mm UVC Ozone Bulb Germicidal Machine UV Disinfection Light Bulb

UVC Ozone Germicidal Uv Lamp E14 10V 3W Washing Machine UV Disinfection Light


			No.
			Specification
			Material


			1
			Glass tube
			Ozone quartz glass


			2
			Lamp core
			10V3W


			3
			Exterior lead wire
			Molybdenum


			4
			Gas sealed
			Inret gas


			5
			Base
			T5G5 White aluminum


			6
			Mercury
			Liquid Mercury



SELF BALLAST 10V 3W BULBS



			No.
			Item
			Code
			Rated value
			Unit
			Tolerance


			1
			Lamp Power
			PL
			3.0
			W
			±15%


			2
			Lamp Voltage
			UL
			10.1
			V



			3
			*Lamp current
			IL
			280*
			mA



			4
			Strengh of 254nm
@30mm distance


			≥450
			μw/cm2



			5
			Steady time of lighting
			T稳
			5
			min



			6
			Average lifetime
			H
			＞8000
			h



			Testing condition
			1 Ballast for testing: 425J400V capacitance

2 Instrument for testing: UI2000 Electronic ballast comprehensive performance tester
3 Testing condition: Temperature:25±1℃ Humidity:30%~50%
4 UV-ray luminometer is tested by UVB-254 probe type of Beijing Normal University,The test values of different illuminance meters are different, and the data are from Youwei Light & Electricity.




for refrigerators, disinfection cabinet, sterilizing box, disinfection cases etc,

Product Description
UVC Is Efficient and SafeUVC Germicidal Fixtures increase the value of all air conditioning and air-circulating systems by:
· Maximizing system efficiency
· Prolonging blower life
· Providing healthier air to breathe
Treating air that passes through an HVAC unit with ultraviolet light will reduce, or eliminate, DNA-based airborne contaminants (bacteria, viruses, mold spores, yeast, protozoa), and provide much healthier air to breathe. UVC Germicidal Fixtures are a labor-free solution that will not harm occupants, equipment or furnishings because they produce no ozone or secondary contaminants. For more than 70 years, tens of thousands have been safely installed in hospitals, clinics, processing plants, commercial offices, manufacturing sites and other commercial facilities and multi-and single-family residences around the world.


Product Description

Features:

1. It is made of quartz glass, and it is divided into two types: ozone-free and ozone-free.

2. It can be connected in series with an incandescent lamp or a special capacitor to insert a 220V/50HZ power supply without a ballast.

3. The number of switching times can reach more than 20,000 times, which is durable. Application range: Especially suitable for refrigerators, disinfection cabinets, microwave ovens, disinfection boxes and other electrical products.

Tag:

Place of Origin:	Zhejiang, China
Brand Name:	UV, Yoway
Certification:	CE,ROSH
Model Number:	ZW3D17Y-Z52

Minimum Order Quantity:	10 pcs
Price:	$3-$25/SET
Packaging Details:	paper box packing
Delivery Time:	5-8 days
Payment Terms:	T/T
Supply Ability:	5000pcs per month

E14 52mm UVC Germicidal Tubes UV Ozone Lamp T5G5 White Aluminum Base

E14 52mm UVC Germicidal Tubes

uv ozone lamp T5G5 White Aluminum Base

E14 52mm uv ozone lamp

UVC Is Efficient and Safe

UVC Germicidal Tubes,

Ultraviolet Germicidal Lamp,

Quartz UVC Light

150W U Shape High Power Germicidal UVC Quartz Lamp Amalgam Purification

150V 10W 170mm Quartz U Shape Germicidal UVC Light Tubes For Hospital Disinfection Light

2w 3w Racket Type UVC Germicidal Tubes Cold Cathode UV Deodorizing Cold Electrode Lamps

8w Facial Steamer Atomizing UV Ozone Lamp UVC Germicidal Tubes 254nm

254nm UVC Germicidal Tubes Cold Cathode UV Lamp 1.2W Toothbrush Sterilization Used

T5 20W UVC Ozone Lamp 15mm Diameter UVC Germicidal Tubes 589mm

H Shape 40W UVC Germicidal Tubes Light 533mm Length G23

DC220V Cold Cathode Light UVC Germicidal Tubes 26 Cubic Meters

No.	Specification	Material
1	Glass tube	Ozone quartz glass
2	Lamp core	10V3W
3	Exterior lead wire	Molybdenum
4	Gas sealed	Inret gas
5	Base	T5G5 White aluminum
6	Mercury	Liquid Mercury

No.	Item	Code	Rated value	Unit	Tolerance
1	Lamp Power	P_L	3.0	W	±15%
2	Lamp Voltage	U_L	10.1	V
3	*Lamp current	I_L	280*	mA
4	Strengh of 254nm @30mm distance		≥450	μw/cm²
5	Steady time of lighting	T_稳	5	min
6	Average lifetime	H	＞8000	h
Testing condition	1 Ballast for testing: 425J400V capacitance 2 Instrument for testing: UI2000 Electronic ballast comprehensive performance tester 3 Testing condition: Temperature:25±1℃ Humidity:30%~50% 4 UV-ray luminometer is tested by UVB-254 probe type of Beijing Normal University,The test values of different illuminance meters are different, and the data are from Youwei Light & Electricity.
